8.1 The Carnegie stages


Synoptic table of the Carnegie stages 7 - 10




Stage 7

Approx. 19th day: Dorsal view 0.4 mm


1
2
3
4
Yolk sac
Primitive streak
Primitive node
Embryonic disk

Characteristic signs:

Mesoblast immigration

Chordal process

Neural plate

Genesis of the blood vessel system and formation of blood

© Professor Kohei Shiota, Kyoto University



Stage 8

Approx. 23th day 0.5 - 1.5 mm


1
2
3
4
Body stalk
Primitive streak
Embryonic disk
Cut edge of the amnion

Characteristic signs:

Pear shaped embryo

Axial process

Neurenteric canal

Neural groove forming

© Professor Kohei Shiota, Kyoto University


Stage 9

Approx. 25th day 1.5 - 2.5 mm


1

2
3
Primitive streak and primitive
groove
Neural folds
Cut edge of the amnion


4
5
Neural groove
Somites

Characteristic signs:

Embryo with somites (1-3 somites)

Pharyngeal membrane

Neural groove

Caudal eminence

Intraembryonic coelom

Cardiac primordium, septum transversum

Placode and auditory pit

© Professor Kohei Shiota, Kyoto University


Stage 10a, 10b

Approx. 28th day 2 - 3.5 mm


1
2a
3
4
Cut edge of the amnion
Neural groove
Neural folds
Somites


2b
2c
2d
5
Neural tube
Caudal neuropore
Rostral neuropore
Yolk sac

Characteristic signs:

Lateral folding

Closure of the neural groove into a neural tube

The 2 first pharyngeal arches appear

Ophthalmic vesicle

Rupture of the pharyngeal membrane

4 - 12 somites

© Professor Kohei Shiota, Kyoto University
