8.1 The Carnegie stages



Synoptic table of the Carnegie stages 14 - 16



Stage 14

Approx. 33th day 5 - 7 mm


1
2
3
4
5
6
7
8
9
Telencephalon
Mesencephalon
Myelencephalon
Ocular primordium
Fourth ventricle
Cervical sinus
Mesonephric cord
Bud of the upper extremity
Bud of the lower extremity

Characteristic signs:

Opthalmic vesicle

Genesis of the endolymphatic canal

Augmented
cephalo-cervical flexure

Cerebellar primordium

Visible ocular primordium

Sixth pharyngeal arch
© Professor Kohei Shiota, Kyoto University


Stage 15

Approx. 36th day 7 - 9 mm


1
2
3
4
5
6
Umbilical cord
Cardiac prominence
Nasal placode
Ocular primordium
Bud of the upper extremity
Bud of the lower extremity

Characteristic signs:

Lens vesicle covered with the ectoderm

Auditory primordium

Genesis of the hand plate
© Professor Kohei Shiota, Kyoto University


Stage 16

Approx. 39th day 8 - 11 mm

1
2
3
4
5
6
7
8
9
10
Umbilical cord
Nasal pit
Nasolacrimal groove
Ocular primordium
Flexura pontina
Flexura cervicalis
Auditory primordium
Cardiac prominence
Hand plate
Foot plate
Telencephalon
Diencephalon
Mesencephalon
Metencephalon
Myelencephalon
Spinal cord

Characteristic signs:

Deep, ventrally lying nasal pit

Pigmentation of the eye

Genesis of the foot plate

Physiologic umbilical hernia

Nasolacrimal groove
© Professor Kohei Shiota, Kyoto University
