8.1 The Carnegie stages



Synoptic table of the Carnegie stages 17 - 19



Stage 17

Approx. 41rst day 11 - 14 mm


1
2
3
4
5
6
Umbilical cord with physiologic umbilical hernia
Nasal pit
Pigmented lens placode
External acoustic meatus
Auricular hillocks
Formation of the interdigital zones

Characteristic signs:

External acoustic meatus

The circumference of the head increases

The trunk lengthens

Fusion of the 6 auricular hillocks

Atrophy of the embryonic tail

Formation of the interdigital zones
© Professor Kohei Shiota, Kyoto University


Stage 18

Approx. 44th day 13 - 17 mm


1
2
3
4
5
6
Cardiac prominence
Nasolacrimal groove
External acoustic meatus
Hand plate with visible finger radiations
Footplate with toe primordium
Primordium of the palpebra (eyelid)

Characteristic signs:

Toe primordium

Nasal primordium

The elbow joint forms

Gonadal gender can be determined in male embryos
© Professor Kohei Shiota, Kyoto University


Stage 19

Approx. 46th day 16 - 18 mm


1
2
3
4
5
6
7
8
Liver prominence
Primordium of the eyelid
Eye
External acoustic meatus
Shoulder
Finger
Toes that are forming
Straightening of the trunk

Characteristic signs:

Lengthening and straightening of the torso

Appearance of the external acoustic meatus

Genesis of the hip and knee joints

Atrophied embryonic tail

Rupture of the cloacal membrane

Maxilla and mandibula
© Professor Kohei Shiota, Kyoto University
