8.1 The Carnegie stages


Synoptic table of the Carnegie stages 11 - 13



Stage 11

Approx. 29th day 2.5 - 4.5 mm


1
2
3
Neural tube
Caudal neuropore
Rostral neuropore that is just closing


4
5
6
Somites
2. pharyngeal arch
1. pharyngeal arch

Characteristic signs:

Closure of the rostral neuropore

Nasal placode

Ophthalmic vesicle

Auditory pit

13 – 20 somites



© Professor Kohei Shiota, Kyoto University


Stage 12

Approx. 30th day 3 - 5 mm


1a
1b

2
3
4
5
6
Maxillar process
Mandibular process
Second pharyngeal arch
Third pharyngeal arch
Somites
Neural tube
Heart
P
M
R
Prosencephalon (forebrain)
Mesencephalon (midbrain)
Rhombencephalon (hindbrain)

Characteristic signs:

Closure of the caudal neuropore

Third pharyngeal arch

Buds of the upper extremities

Cervical sinus

21–29 somites
© Professor Kohei Shiota, Kyoto University


Stage 13

Approx. 32th day 4 - 6 mm


1a
1b
2
3
4
5
6
7
8
9
10
Maxillary process
Mandibular process
Second pharyngeal arch
Third pharyngeal arch
Fourth pharyngeal arch
Somites
Buds of the upper extremities
Left cardiac ventricle
Left cardiac atrium
Body stalk
Embryonic tail

Characteristic signs:

Buds of the lower extremities

Lens placode

Auditory pit

Fourth pharyngeal arch

More than 30 somites
© Professor Kohei Shiota, Kyoto University
